Scrap Analysis¶

Category: Scrap · Widget ID: scrap.pareto

What it shows¶

Analyzes and visualizes scrap reasons as a ranked (Pareto) breakdown, so you can see which reasons cause the most scrap.

Data and refresh¶

Data source: Reports API.
Time range: Respects the selected time period (aggregated over the whole window).
Machine filter: Respects the selected machine(s).
Widget locks: You can lock this widget to its own machine and/or time range (Machine lock / Time lock) so it ignores the dashboard filters. See Custom Dashboard.

Configuration¶

Open the widget's filter menu (slider icon), then select Configure to change:

Group by: Scrap Reason, Machine, Track, or Station
Chart type: Pareto, Bar, Pie, Doughnut, or Table
Top N results
Show legend

How to read it¶

Reasons are ranked by scrap quantity, largest first. Focus improvement on the top contributors.

Interactions¶

Load more — show additional scrap reasons.
Widget filter (top-right icon) — open the widget's own settings to change its display.

Screenshot¶

Scrap Analysis pie chart with scrap reasons

Troubleshooting¶

Widget shows no data -> No events in the selected machine/period, or a filter is too narrow -> Widen the time range or change the machine, then refresh once -> If a machine that normally reports data stays empty, use Troubleshooting > Connectivity.
